Cable cutting and stripping machine TAUS 3T

automaticelectric

The CUTTING AND CRIMPING AND STRIPPING MACHINE GM TAUS 3T is a fully automatic machine and is suitable for the automatic processing of single-core wires up to 6.0 mm2 in section. The CUTTING AND CRIMPING AND STRIPPING MACHINE GM TAUS 3T has an electric operation with fully electronic setting of all processing parameters and allows you to automatically perform cutting to size, stripping and crimping of bare terminals on single-core wires even on both sides. With the CUTTING AND CRIMPING AND STRIPPING MACHINE GM TAUS 3T you have the possibility of storing up to 100 programs, with rapid setting via LCD touch screen display of all processes. This machine is suitable for processing with maximum precision of all work stations, maintaining a very high speed without the aid of an operator. The CUTTING AND CRIMPING AND STRIPPING MACHINE GM TAUS 3T is supplied complete with all accessories, instruction manual, after-sales assistance, spare parts, 24-month warranty and complete with CE certifications. Technical Features: ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - No ABSORBMENT - 3000 W STRIPPING LENGTH - Head 0,5÷10 mm – Tail 0,5÷10 mm WORKABLE SECTIONS - 0,1÷6,0 mm² CUTTING LENGTH - 40 mm÷9900 mm FEEDING - 4 Servo Motors WORKABLE CABLE - PVC-Teflon-Silicon-Glass CRIMPING FORCE - 3T, Miniapplicators to be defined PRODUCTIVITY - L = 100 mm, 3.000 – 4.000 pcs/h TOLERANCE - ≤ 0.002xL (L= Cutting Length) DISPLAY - Touch Screen LCD Liquid Cristal Display MEMORY - 100 Programs WEIGHT - 350 Kg DIMENSIONS - 800x600x1600 mm (WxDxH)
