Adhesive tape taping machine 7CL

for cablesautomatic

Product overview
The electronically controlled TAPING MACHINE 7CL is designed for precise tape-wrapping of a wide range of electrical wiring, from simple harnesses to complex cable assemblies. A high-precision tape guide and adjustable wrapping pitch ensure symmetrical, accurate coverage. Program memory (30 programs) enables fast changeovers between wiring types without manual reconfiguration.

Features

• Compatible with various adhesive tape materials (excludes insulating paper tapes)
• Maintains smooth alignment and prevents bending; each turn overlaps the previous by half for uniform coverage
• Multiple winding patterns: point winding at fixed positions or winding at different positions
• Adjustable revolutions and winding speed with capacity display
• Quick blade replacement for reduced downtime

Technical features
Power supply: Single-phase 230 V 50/60 Hz
Pneumatic supply: No
Power consumption: 280 W
Workable diameter: Up to 40 mm
Taping length: Unlimited
Taping width: 5 ÷ 35 mm (please specify when ordering)
Tape hole inner diameter: 37/32 mm (please specify when ordering)
Tape material: PVC, velvet or similar
Productivity: Up to 12 turns/s
Display: Touch-screen LCD
Memory: 30 programs
Weight: 40 kg
Dimensions (WxDxH): 600 x 470 x 400 mm

Technical specifications

• Power supply: Single-phase 230 V 50/60 Hz
• Pneumatic supply: No
• Power consumption: 280 W
• Workable diameter: Up to 40 mm
• Taping length: Unlimited
• Taping width: 5 ÷ 35 mm (to be confirmed)
• Tape hole inner diameter: 37/32 mm (to be confirmed)
• Tape material: PVC, velvet or similar
• Productivity: 12 turns/s max
• Display: Touch-screen LCD
• Memory: 30 programs
• Weight: 40 kg
• Dimensions (WxDxH): 600 x 470 x 400 mm

Additional services

• Wide product range: in-house production and top market brands
• Customization of equipment and production lines to customer specifications
• Design and manufacture of special systems
• Technical assistance at supplier site or on customer premises
• Spare parts supply for all offered machines
• Installation, commissioning and operator training
• Courses, demonstrations and on-site tests on customer samples (free samples available)
• Feasibility studies and production adaptation
• Scheduled maintenance and preventive service
• Trade-in / exchange of old systems
• Supply of consumables and accessories: steel, carbide and titanium blades, mini-applicators, electric terminals, pre-insulated connectors, splice strips
• Purchase, revaluation and resale of used equipment
• Sale of components and accessories from major brands
• On-site demonstrations and seminars
