Feed robotic cell

for bottles

Vial feeding system – chaotic This vial-feeding system is made to unpack vials/bottles from Plastic twin-wall sheets and feed them into turntables/bi-flow belts. The gripper is the core of the system; it handles the Plastic twin-wall sheets and accepts the vial groups in a bulk, respectively places them in the incoming area of the turntable/bi-flow belt. Depending on the required degree of automation, the Plastic twin-wall sheets can either be manually placed onto a buffer conveyor by an operator or automatically be taken from the pallets by the robot. The recognition of the boxes on the pallets is executed by a 3D camera. The Plastic twin-wall sheets bottoms and covers are transferred into a box provided for this purpose. Fields of application : • pharmaceutical industry • unpacking of vials from Akylux boxes without separators • feeding of vials at the inlet of inspection machines/packing systems • operations at new and existing machines Performance/technical data • up to 400 vials/min • formats 2R, 6R, 10R, 30ml, 50ml vials • quick change system for gripper with centred feedthrough of media • de-palletizing with 3D camera Options : • RFID-coded gripper systems • operations without mech. safety housing (coexistent operations) • monitored line clearance • AGV connection
