OverviewThe Goubard FR forklift fork extensions instantly extend the reach and load-bearing length of forklift tines for handling extra-long pallets, oversized crates, or reaching goods stacked on the far side of lorry beds. Designed and manufactured in France from heavy-duty 5 mm structural steel, these fully enclosed box-section extensions provide superior bending resistance and workplace safety. Sold in pairs, they support a safe working load of up to 2000 kg across the tips and strictly comply with the dimensional calculation criteria of the international ISO 13284 standard.
Key benefits- Safe oversized load handling: stabilizes double-length pallets, long timber packs, and wide containers without tipping hazards.
- Fully enclosed tubular profile: four-sided closed box construction provides maximum torsional strength and prevents spreading under heavy loads.
- Full ISO 13284 compliance: engineered to meet the normative formula (B1B/0.6), requiring base forks to support at least 60% of the total extension length.
- Positive heel-pin locking: heavy-duty removable retaining pins with safety clips lock securely behind the fork heel, preventing forward slippage.
- Heavy-duty 5 mm steel: exceptional wear resistance against impact, complete with tapered entry tips for easy pallet entry.
Benefits & ergonomicsGoubard FR fork extensions eliminate dangerous improvised operations where long or awkward loads overhang standard-length forks. The tapered nose profile slides easily beneath pallets without snagging. Mounting takes just seconds: the forklift tines drive straight into the extensions resting on the floor, and the driver inserts the retaining pins behind the fork heels. This cost-effective solution avoids the expense of purchasing specialized vehicles or permanently fitting longer forks.
Design & constructionManufactured from welded heavy-gauge 5 mm steel sheet with continuous seam welds. Internal dimensions are tightly toleranced to eliminate excessive play and vibration on the base forks. The rear section features reinforced brackets housing a zinc-plated steel safety pin and retaining clip.
ApplicationsSingle-side truck unloading, transporting double pallets, and handling long machinery crates, timber packs, metal profiles, and composite sheets. Recommended for logistics distribution hubs, builders' merchants, manufacturing plants, and industrial maintenance yards.
Models & specificationsSold in pairs—safe working load of 2000 kg across fork tips—5 mm steel thickness:
- FRP10015: Max fork size 40 × 80 mm—Internal section 50 × 100 mm—Usable length 1500 mm—Weight: 38 kg
- FRP12017: Max fork size 45 × 100 mm—Internal section 55 × 120 mm—Usable length 1700 mm—Weight: 49 kg
- FRP12020: Max fork size 45 × 100 mm—Internal section 55 × 120 mm—Usable length 2000 mm—Weight: 58 kg
- FRP14517: Max fork size 45 × 125 mm—Internal section 60 × 145 mm—Usable length 1700 mm—Weight: 57 kg
- FRP14520: Max fork size 45 × 125 mm—Internal section 60 × 145 mm—Usable length 2000 mm—Weight: 67 kg
- FRP17020: Max fork size 50 × 150 mm—Internal section 65 × 170 mm—Usable length 2000 mm—Weight: 77 kg
Technical specifications- Attachment type: fully enclosed box-section fork extensions
- Packaging: sold in pairs
- Load rating: 2000 kg distributed across the pair at fork tips
- Profile: 4-sided closed tubular profile
- Steel thickness: 5 mm
- Retention system: removable safety pin behind fork heel
- Normative standard: compliant with ISO 13284 (B1B/0.6)
- Materials / Finishes: painted steel, hot-dip galvanized steel, or stainless steel
- Options: custom bespoke fabrication for non-standard fork dimensions or lengths
