Dimensioning system GRAM L635

Overview
The GRAM L635 (powered by MetriXFreight) is an ultra-fast, verified dimensioning system for long and oversized freight. Designed for certified logistics operations, it captures dimensions, optional weight and photo documentation automatically for long, oversized and bulky goods without slowing down material flow. Capacity to 10,000 kg, resolution from 1 kg, CE-M / OIML verified for legal-for-trade applications.

Key features

• Measures long and bulky goods up to 650 × 260 × 260 cm.
• Dimensional accuracy: 20 mm (length/width), 10 mm (height) (OIML).
• Ultra-fast measurement cycle: approx. 200 milliseconds for high throughput.
• Static, contactless architecture (no moving components) for stable measurements, minimal maintenance and high availability.
• Automatic photo documentation with color image per measurement; option to capture up to six photos per item using additional cameras.
• Capacity and weighing: platform capacities reported up to 10,000 kg (typical capacity ranges 3000 kg up to 10,000 kg depending on configuration) with resolutions from 1000 g up to 2000 g depending on model/configuration.
• CE-M / OIML verified configuration available for legal-for-trade billing and volume-based billing in regulated logistics environments.
• Robust industrial construction for reliable indoor use; IP50 platform protection.

Connectivity & Integration

• Standard Ethernet connectivity; optional WLAN or LTE.
• REST API and QR-code output for seamless integration.
• File-based data exchange: CSV, XLSX, PDF including image documentation.
• Designed for direct integration into WMS, TMS and ERP systems to eliminate manual data entry and ensure consistent master data.

Applications

• Inbound logistics, outbound dispatch and cross-docking for long/oversized freight.
• Long goods such as profiles, pipes, construction materials, pallets and bulky freight that exceed standard dimensioning limits.

Operational highlights

• Static architecture suitable for continuous, multi-shift environments.
• High throughput with measuring time of ~200 ms reduces bottlenecks in time-critical operations.
• Automatic photo documentation improves traceability and internal verification.

Performance — selected specifications
Capacity Range: 3000 kg up to 10000 kg
Resolution: From 1000 g up to 2000 g
Trade Approval: Yes (CE-M / OIML verified options)
Tare Memories: Memory of 20 preset tares
Weighing Units: g, kg

Characteristics / Specifications techniques

• Model family: GRAM L635 (powered by MetriXFreight).
• Maximum measurable object size: up to 650 × 260 × 260 cm.
• Dimensional accuracy: 20 mm (length/width), 10 mm (height) under OIML class specifications.
• Measuring time: approx. 200 ms (ultra-fast measurement cycle).
• Weighing capacity: platform configurations from 3000 kg up to 10000 kg (depending on selected platform/model).
• Weighing resolution: selectable from approx. 1000 g up to 2000 g depending on configuration.
• Legal-for-trade verification: CE-M / OIML verified versions available.
• IP protection: Platform IP50 (indoor use); indicator options with higher IP ratings available.
• Construction materials: robust industrial platform; indicator housing options (e.g. ABS or AISI 304 stainless steel for certain indicators).
• Plate / platform dimension options: from 3000 × 1500 mm up to 6000 × 2450 mm (depending on platform model and configuration).
• Connectivity: Ethernet standard; optional WiFi (WLAN) or LTE; indicator interfaces include RS-232C, TTL and optional USB-A.
• Integration: REST API, QR-code output, and file export (CSV, XLSX, PDF) including image documentation.
• Photo documentation: one color image per measurement standard; optional up to six photos per item with additional cameras.
• Power options (indicator/platform accessories): examples include lead-acid battery options with typical service times (e.g. 30/60 h) for specific indicator models.
• Architecture: static, contactless system (no moving components) to reduce mechanical wear and maintenance.
