Truck-mounted crane TLS 75 14T SRtowerfor constructionlifting
Add to favorites
Compare this product
Characteristics
- Configuration
- truck-mounted
- Structure
- tower
- Operating environment
- for construction
- Applications
- lifting, loading, handling
- Lift capacity
Min.: 1,900 kg
(4,188.8 lb)Max.: 14,000 kg
(30,864.7 lb)- Max load at max radius
2,090 kg
(4,608 lb)- Horizontal reach
Min.: 10 m
(32'09" )Max.: 75 m
(246'00" )- Hoisting speed at max load
11 m/min, 37 m/min, 100 m/min
- Crane engine power
55 kW
(74.8 hp)- Swing speed
0.3 rpm, 0.6 rpm, 0.9 rpm
(1.885 rad.min-1, 3.77 rad.min-1, 5.655 rad.min-1)- Total counterweight
15,500 kg, 18,250 kg, 19,500 kg, 20,750 kg, 22,000 kg
(34,171.651 lb, 40,234.363 lb, 42,990.141 lb, 45,745.919 lb, 48,501.698 lb)
Description
The Sáez tower crane range has a common theme, one of being designed and engineered to be efficient work horses on a work site. In keeping with this aim, many of our flat top models include a version designed to work exclusively in 2 falls. These models allow the user to avoid changing the trolley configuration on site.
This TLS 75 2-falls version is capable of loading up to 2,090 Kg at the tip and the hoist capacity increases to 14 tons. In line with the pursuit of overall efficiency, this crane shares many aspects of its configuration with other TLS 75 models, allowing the hoist chart to be easily adapted to the job in hand.
