Cold laminator SLS series

Solventless Laminator Solventless laminator uses solvent-free adhesives to combine together two or multiple types of substrates, such as plastic film, paper, aluminum foil, etc. This lamination machine can be used for duplex lamination, triplex lamination to create a single flexible laminate which is advantageous in terms of cost efficiency, safety and environmental protection. We have 2 standard types of solventless laminators for you to choose from. If you have other specific requirements, we are able to offer you custom-engineered laminators to solve your various laminating needs. Standard web width: 1050/1250mm (can be customized, Max. 1600mm) Applicable substrate: rolls of plastic film, paper, aluminum foil. 1）SLS-400 Specifications Maximum machine speed: 400m/min Tension control precision: ±2N 2）SLS-350 Specifications Maximum machine speed: 350m/min Tension control precision: ±2N Configurations Solventless laminator consists of unwinding unit, coating unit, laminating unit, and rewinding unit. Unwinding unit 1. Shaftless unwinding unit as a robust structure, easy to operate and time saving. 2. Designed with dancer roll to efficiently control tension. 3. PLC system controls unwinding speed, accomplishing automatic speed regulation in synchronized motion with solventless laminator. Coating unit 1. Adopting 5-roll coating method, different amount of adhesives can be applied by regulating speed differential of steel transfer roller and rubber transfer roller.
