Simple mechanical structure.
Sturdy and durable
Can operate stably for a long time.
Wide usage scenario
Capable of handing various harsh working condition.
Easy to maintain
Long service life,easy maintenance and cheap.
TECHNICAL PARAMETERS
SYSTEM - DESCRIPTION - 106J - Comments
Feeder - Feeding capacity (t/h) - 450 -
Max input size (mm) - 600 -
Feeding height (mm) - 4150 -
Hopper volume (m³) - 5 -
Vibrating feeder - Length × Width (mm) - 4000 × 1040 -
Power (kW) - 3.7 × 2 -
- Jaw crusher - C106 -
34Max input size (mm) - 600 -
Crusher weight (t) - 18 -
Power (kW) - 110-6 -
Main Conveyor - Discharge height (mm) - 3000 -
Length × Width (mm) - 10000 × 1200 -
Power (kW) - 15 -
Tail conveyor (Optional) - Discharge height (mm) - 2100 -
Length × Width (mm) - 3600 × 500 -
Power (kW) - 3 -
Iron remover (Optional) - Length × Width (mm) - 1670 × 800 -
Power (kW) - 3 -
Total working power (kW) - 136(139) - The brackets contain the iron remover
Working dimension (L × W × H, mm) - 14300 × 4800 × 4150 -
Transport Dimension (L × W × H, mm) - 14300 × 3400 × 3850 - Remove one side platform
Description:
1. The parameter in brackets is the onboard generator scheme.
2. Crusher processing capacity is related to stone hardness, feed size, and discharge size.
3. Basic configuration:manual control 、wireless remote control、Automatic feeding system.
4. Options:side conveyor belt 、iron remover 、water spraying system.
