Venturi vacuum pump GMVP 230/090lubricatedsingle-stagestainless steel
Add to favorites
Compare this product
Characteristics
- Technology
- Venturi
- Lubrication
- lubricated
- Number of stages
- single-stage
- Other characteristics
- stainless steel
- Ultimate vacuum
Max.: 400 mbar
(5.8 psi)Min.: 33 mbar
(0.48 psi)- Flow rate
Max.: 190 m³/h
(6,709.79 ft³/h)Min.: 165 m³/h
(5,826.92 ft³/h)- Power
5.5 kW
(7.48 hp)- Operating temperature
70 °C, 100 °C
(158 °F, 212 °F)- Length
650 mm
(25.591 in)- Width
345 mm
(13.58 in)- Height
350 mm
(13.78 in)- Noise level
70 dB
- Weight
91 kg
(200.62 lb)
Description
Monoblock design, no coupling.
Plates are stainless steel.
shaft not contact with the medium.
Safe and efficient operation.
Able to pump every kind of gases and vapors.
Works quiet and reduced vibration.
No need to lubrication.
Low operation and investment cost.
Minimum maintenance with high efficiently.
No metallic contact of the rotating parts.
Provide 0 leakproofing with mechanical seal.
