MMA welder NEOPULSE 400 CW

TIGMIG-MAGthree-phase

The NEOPULSE 400 CW is a three-phase, pulsed, MIG/MAG generator developed for heavy industry. The NEOPULSE 400 CW is mobile and equipped with a cooling unit and a powerful reeling system, making it ideal for handling demanding pulsed applications. Both intuitive and highly practical, its digital interface makes adjusting the welding settings very easy. MIG/MAG : - steel and stainless-steel wire: Ø 0.6 to 1.6 mm - aluminium wire: Ø 0.8 to 1.6 mm - CuSi and CuAl wire: Ø 0.8 to 1.6 mm - flux-cored wire: Ø 0.9 to 2.4 mm MMA DC / Pulsed: basic, rutile and cellulosic electrodes (up to Ø 6 mm). TIG DC LIFT / PULSED. Gouging (up to Ø 6.5 mm) SYNERGIC mode: After entering two data (material/gas torque or wire diameter), the NEOPULSE automatically determines the optimal welding conditions and automatically adjusts the settings (wire feed speed, voltage, current and arc length). Calibration of welding accessories and motor reel speed, to adjust the displayed voltage measurement and improve energy data. Energy, data display and post-welding energy data is available according to standards EN1011-1, ISO/TR 18491 and QW-409. Portability: download/backup/transfer user JOBS and machine configuration information from a USB stick. Tracking: trace/record all welding stages, bead by bead, during industrial processing within the framework of standard EN ISO 3834.
