Hose crimping machine CRIMPMATIC 600

automatichydraulic

Crimping press with frequency-controlled drive and with 3-point applicator fixture. The compact design with strong base frame and central force transmission into the press ram guarantee high Cpk-values and silent running. It is suitable for processing terminals for wire cross-sections of up to 6 mm² and a max. material thickness of 1 mm. Including spool arm, foot switch and moveable safeguard. Technical specifications: Press force: 20 kN Drive power: 0.75 kW Drive: frequency-controlled drive motor Supply voltage: 230 V, 1~/N/PE, 50/60 Hz Wire cross-section: up to 6 mm² (10 AWG) Stroke: 41 mm Closing height: 135.78 mm Cycle time, adjustable: 0.3 s Sound pressure level: < 70 dB (A) Dimensions (W x D x H): 365 x 420 x 780 mm (without spool arm) Weight: about 125 kg
