Liquid tank

oilfor petroleum productsfor hygienic applications

Overview HBE cast aluminium oil tanks provide space-saving storage and lower freight costs through stackability and low weight.

Construction and options The cast bodies feature all-round ribbing and good heat dissipation due to the aluminium construction. All tank sizes can be supplied with openings for sight glasses or with fully machined lids according to customer specifications. Matching oil sumps complete the product range. Complete lid machining is performed on a modern plasma plant.

Product features

• From AB 12 supplied with feet; from AB 44 optionally with castors
• Flat gasket between lid and tank made of paperboard or rubber cork for AB 3.5–AB 20
• Toroidal sealing ring (endless, without contact spot) Ø 6 mm NBR for AB 30–AB 70
• Individual lid machining available on request with short lead time

Characteristics / technical specifications

• Material: Cast aluminium
• Design: Cast bodies with all-round ribbing
• Heat dissipation: Good heat dissipation due to aluminium and ribbing
• Stackability: Stackable for space-saving storage
• Weight: Low weight to reduce freight costs
• Sealing options: Flat gasket (paperboard or rubber cork) for AB 3.5–AB 20; toroidal sealing ring Ø 6 mm NBR for AB 30–AB 70
• Mounting/handling: From AB 12 with feet; from AB 44 optionally with castors
• Options: Openings for sight glasses; complete lid machining (plasma plant)
• Related products: Matching oil sumps available
• Sizes referenced: AB 3.5; AB 12; AB 20; AB 30; AB 44; AB 70
