Diesel engine hedge trimmer LLRD-Y series

Engine Laidong 3-cylinder diesel engine KOOP DIESEL GENERATOR Power（Ps） 30 20 Voltage（V） 12 380 Chassis - Driven by hydraulic motor and can rotate 360° Chassis driven mode - Driven by hydraulic pump - Driven by electric motor Cutting width（mm） - 1220 - 1700 Cutting height（mm） - 500~6000 Mower arm - 3-arm lifting +1 telescopic arm Major arm lifting angle（°） - 45 Major arm length（mm） - 1700 Cantilever angle（°） - 100 Cantilever length（mm） - 1060 telescopic arm swing angle（°） - 100 Outer boom length（mm） - 1450 Fly jib length（mm） - 1500 Fly jib Expansion stroke （mm） - 1300 Cutter turnover angle（°） - 360 - -45~45 Cutter driven mode - Driven by hydraulic motor - Driven by hydraulic cylinder Blade driven mode - Driven by hydraulic motor - Driven by 3.0kw electric motor Blade rotation speed（r/min） - 0-2300 - 0-2900 Working speed（km/h） - 5~10 Operation mode - Operated by 24 points Radar multifunctional remote controller, safer Display - LCD Moving mode - Vehicle mounted type
