dry air dryer / continuous / for plastic pellets / cleaning
JETBOXX®stand-alone

{{requestButtons}}

Characteristics

  • Technology:

    dry air

  • Batch/continuous:

    continuous

  • Applications:

    for plastic pellets

  • Associated function:

    cleaning, dehumidifying

  • Other characteristics:

    compact, stainless steel, modular, high-performance, with timer

Description

Placement next to the processing machine and conveying to the feeding section
JETBOXX® stand-alone dryers can be used anywhere, where top-mounted dryers fail because of weight / or space reasons. Assembly of the system components on a base frame for a drying before / while the processing with conveying of the dryed granules onto the injection unit.

When changing the setting of task the components can be combined easily or used as top-mounted dryers again.
Conveying onto feed section
2nd conveyor
By using ambient or clean dry air, the material can be conveyed from suction box at dryer outlet to the feeding section, depending on the hygroscopicity of the dried granules/ground material.
One or two-component conveyors are available, optionally with or without dedusting function.
Because of their construction HELIOS compressed air conveyors are able to convey the material gently up to 8m.

Conveying with dry air
Suction devices with dry air conveying
3 new types of suction devices allow a 100 percent avoidance of moisture adsorption of the dried material anew in the waiting or conveying mode.

Suction / discharge
For the conveying of the dried granules by using Venturi suction lances or for discharging for cleaning purposes 4 devices are available.
