Characteristics

Functions
automation, database, plant design
Applications
industrial
Type
3D
Other characteristics
AutoCAD

Description

CADWorx® Plant Design Suite is an integrated, complete AutoCAD®- and BricsCAD®-based software series for plant design that provides intelligent drawing and database connectivity, advanced levels of automation, and easy-to-use drafting tools. By including the ability to choose the design platform, CADWorx® continues to expand upon and provide powerful and adaptive tools that enable quick and easy creation of fully intelligent 3D plant models. The comprehensive series of CADWorx design tools allows for the option to run on the AutoCAD or BricsCAD platform and includes piping, structural steel, equipment, process and instrument diagrams, and design review, plus automatic isometrics and bills of material. CADWorx is quick and easy to set up and use, so design can begin immediately. The bi-directional links between CADWorx and analysis programs for pipes and vessels enable designers and engineers to easily share information while keeping the drawings, models, and related information continuously synchronized as changes are made. The fast processing and highly refined user-interface features in CADWorx empower users to work efficiently together, even on large models.
