LED variable-message sign HGM series

full-matrix

Overview
Monochrome LED graphic panels from the HGM series designed for indoor and outdoor applications. PC programming with dedicated software is included. Supports scrolling text, slide presentations, animated GIFs and logos, time/date display and scheduled message playback.

Model: HGM-96X16-P16
LED graphic panel 96×16 pixels, monochrome.

• Graphic area: 1536 × 256 mm
• Pixels: 96 × 16
• LED pitch: 16 mm
• Total characters per page: 32
• Number of text lines: 2
• LED count: 1536
• LED type: SMD, viewing angle: 120°
• Enclosure: oven-painted aluminium, dark grey

Model: HGM-144X16-P16
LED graphic panel 144×16 pixels, monochrome.

• Graphic area: 2304 × 256 mm
• Pixels: 144 × 16
• LED pitch: 16 mm
• Total characters per page: 48
• Number of text lines: 2
• LED count: 2304
• LED type: SMD, viewing angle: 120°
• Enclosure: oven-painted aluminium, dark grey

Model: HGM-96X32-P16
LED graphic panel 96×32 pixels, monochrome.

• Graphic area: 1536 × 512 mm
• Pixels: 96 × 32
• LED pitch: 16 mm
• Total characters per page: 64
• Number of text lines: 4
• LED count: 3072
• LED type: SMD, viewing angle: 120°
• Enclosure: oven-painted aluminium, dark grey

Model: HGM-96X16-P20
LED graphic panel 96×16 pixels, monochrome, 20 mm pitch.

• Graphic area: 1920 × 320 mm
• Pixels: 96 × 16
• LED pitch: 20 mm
• Total characters per page: 32
• Number of text lines: 2
• LED count: 1536
• LED type: SMD, viewing angle: 120°
• Enclosure: oven-painted aluminium, dark grey

Model: HGM-144X16-P20
LED graphic panel 144×16 pixels, monochrome, 20 mm pitch.

• Graphic area: 2880 × 320 mm
• Pixels: 144 × 16
• LED pitch: 20 mm
• Total characters per page: 48
• Number of text lines: 2
• LED count: 2304
• LED type: SMD, viewing angle: 120°
• Enclosure: oven-painted aluminium, dark grey

Model: HGM-96X32-P20
LED graphic panel 96×32 pixels, monochrome, 20 mm pitch.

• Graphic area: 1920 × 640 mm
• Pixels: 96 × 32
• LED pitch: 20 mm
• Total characters per page: 64
• Number of text lines: 2
• LED count: 3072
• LED type: SMD, viewing angle: 120°
• Enclosure: oven-painted aluminium, dark grey

Technical specifications / Features

• Series: HGM (multiple models available with different resolutions and LED pitch)
• Use: indoor and outdoor
• Programming: via PC with dedicated software included
• Supported content: scrolling text, animated GIFs, logos, time/date display, scheduled messages
• LED type: SMD with 120° viewing angle
• Construction: oven-painted aluminium enclosure, dark grey
• Available variants: combinations of pixel matrices and LED pitch (e.g. 96×16, 144×16, 96×32) and 16 mm or 20 mm pitch to suit graphic area and LED density
