Installation, Operation and Maintenance Procedures
Remove lid by four screws, lead cable through the cable gland and connect to terminal with required tapping.
Check that the gasket is fitted correctly on to the lid. Do not use any lubricants on the gasket.
Screw lid back into place by four screws with a torque of 1,8 Nm to assure the IP rating.
To change the position of the loudspeaker, please adjust the standard U- bracket (by loosening / tightening the screws) as required.
Use only certified/specified cable glands and blanking plugs, reflecting the same IP rating and temperature range as the loudspeaker.
Standard model delivered with two M20 Ex approved plastic blinding plugs.
DSP-15 EExmNL(T) can be supplied with three different bracket systems, according to customer requirements.
For optimum performance, always use the correct voltage / power and operate within the frequency limits as stated.
Do not open loudspeaker when energized.
This loudspeaker is supplied with a two years warranty against defective workmanship.
