Quality control analyzer HT9023

3-phase electrical networkspower qualityharmonic

Product Overview
The HT9023 is a professional TRMS clamp meter designed for measuring AC, DC, and AC+DC currents up to 1000A. It features WiFi connectivity for data transfer and is compliant with CAT IV 600V and CAT III 1000V safety standards.

Main Features

• TRMS
• Current measurement range: 1000A
• AC/DC current: AC + DC
• AC/DC voltage: 1000VAC/1500VDC
• Frequency
• Resistance and continuity test with alarm
• Phase sequence and concordance
• Voltage and current measurement/recording
• Active, reactive, apparent energy measurement/recording
• Cos Phi, power factor measurement/recording
• Harmonics V-I measurement up to the 25th with THD% calculation
• Inrush current measurement: Dynamic INRUSH
• Maximum clamp diameter: 45mm
• Measurement points: 9999
• Backlight
• Autorange
• Auto power off
• Non-contact AC voltage detection
• Data HOLD function
• MIN/MAX function
• PEAK function
• Relative measurement
• Datalogger and graph
• Data storage memory
• PC/Smartphone or tablet interface: WiFi
• AC/DC voltage in single/three-phase systems: Single-phase
• AC/DC current in single/three-phase systems: Single-phase
• Inrush current for electric motors
• Neutral-Earth voltage
• Neutral current
• Max number of selectable parameters simultaneously: 60
• Recording with selectable integration period: 1s-15min
• Indicative memory duration (in days @ PI=30sec): 63 hours
• Recording autonomy indication
• Internal memory capacity: 2MB
• Instantaneous sampling value storage
• Summary table of main electrical parameters
• Voltage/Current waveforms
• Harmonics and THD% tables or histograms
• Vector diagram of voltages/currents
• Power supply: 2x 1.5V AAA
• Measurement category: CAT IV 600V CAT III 1000V
• Weight in grams (batteries included): 420
• Dimensions (LxWxH) (mm): 252x88x44

Standards

• CE MARK
• IEC/EN61010-1
