Characteristics

Operation
electric
Type
wire rope
Application
lifting, haulage, pulling
Other characteristics
planetary gear, rotary drum, rugged, speed control
Capacity

Min.: 800 kg
(1,763.7 lb)

Max.: 3,000 kg
(6,613.9 lb)

Speed

Min.: 19,000 mm/min
(12.5 in/s)

Max.: 45,000 mm/min
(29.5 in/s)

Description

Electric winch 800 kg. Range of electric winches suitable for intensive use in severe conditions when lifting or pulling/hauling. Use: • - Lifting or pulling/hauling applications • - Industry (production line supply, waste removal, maintenance, loaders, en-mass conveyors...) • - Building and public works (bridge-laying, freight elevators, handling, assembly, high-rise sites...) • - Launch of bridges • - Railways: wagon or train haulage • - Traction of heavy loads • - Conveyor belt tensioning... • - Extreme sturdiness and reliable parts by HUCHEZ. • - Wall mounting possible. • - 230/400 V - 50 Hz three-phase motor. IP 55 Protection. P = 7,5 kW. • - Coaxial model. • - Low voltage control protects the user from electrical risks. It makes it possible to operate a wide range of options: from limit switch to radio control, including a load limiter and a rope slack switch... • - Reliable electric and electronic components. • - The control unit is proposed separately to give a greater freedom to users and to provide the means for adapting to every situation. • - 24 V extra-low voltage control unit comprising of contactors, power line breaker, thermal circuit breaker, not disconnectable pendant control (3 m of cable). Variable speed extra-low voltage control unit available comprising of: power line breaker, variable speed control, braking resistance, pendant control with potentiometer (3 m of cable). • - Limit switch obligatory when lifting. • - Electronic load limiter optional. • - Fully sealed planetary gear reducer (reduced maintenance). • - Standard length of drum: 600 mm. • - Numerous rope outlets possibilities.
