Compressed air lubricator 310L2

Stainless steel AISI 316L oil fog lubricator “series 10”. Connections 3/4’’-F and 1’’-F by flanges screwed to the body. Other connections available on request. The lubricator add oil fog to the air stream that flows inside, is installed upstream of air operated tools and equipment. The oil flow is proportional to the air flow, by increasing the air flow the oil flow also increase maintaining the right proportion between air and oil. Available the ATEX 2014/34/EU version. Brand CE ExII2GcIICTX, CE ExII2DcIIICTX. For use in potentially explosive atmospheres zones: 1, 21, 2, 22 (not for use in mines and zone 0). Available the EAC-EX TP TC 012/2011 versions for the Russian market. The product complies with the directive 2014/68/EU (PED). It is possible to assemble units composed of: Filter + Regulator + Lubricator; Filter-Regulator + Lubricator IN/OUT Connection 3/4”-F | 1”-F | 1”1/4”-F | 1”1/2-F (GAS/NPT) | UNI EN 1092-1 | ASME B16.5 Working Temperature - Standard -4°+176°F | Available on request from -76°F up to +608°F Oil Tank Capacity ~500 CC Weight ~7,7 lb Certifications PED 2014/68/UE | ATEX 2014/34/UE | EAC TR CU 010 | EAC Ex TR CU 012 Internals and Body Material Stainless steel AISI 316L Seals Material FPM | FVMQ | FFKM Spare Parts Kit - O-rings | Steel ball for check valve
