Motor-driven rotary table
horizontalverticaltilting

motor-driven rotary table
motor-driven rotary table
motor-driven rotary table
Add to favorites
Compare this product


Characteristics

Operation
motor-driven
Configuration
horizontal, vertical, tilting
Applications
for machine tools, for packaging lines, dosing, loading, for the food industry
Other characteristics
rotating, high-precision, high-speed, PLC-controlled, automatic, screw
Diameter

Max.: 50 mm
(2 in)

Min.: 0 mm
(0 in)

Description

PLC controlled rotating table to load the desired amounts of large sized hardware such as screws, nuts, bolts and couplings. • PLC controlled management of data related to the table, product length, minimum distance between products, number of product per pack, number of pieces per batch. • DC motor controlled by a microprocessor. • Rotating external crown with 50 mm wide product support surface. • Conical disc to provide uniform product feed on the external crown. The rotation of the disc is synchronised with that of the crown and protected by a clutch device against mechanical jamming caused by the product. • Adjustable external wall to obtain one single file of products when they reach the rotating table discharge area. • Sensor to control the product level on the table, adjustable to obtain a consistent flow of products from the feeder hopper. • Conveyor belt accelerator at the table discharge point to separate the products and arrange them correctly for the counter unit. • Machine built according to CE Standards.
