Multi-compartment silo G/S14/S18/S24

for wood pelletsdustwood chips

IMAS AEROMECCANICA includes, in the wide range of dust collectors that it uses for the filtration of dust and shavings deriving from wood processing, a series of silos suitable for the filtration and storage of the material, equipped with all the technical devices (anti-compaction bridge breaking system, speed-controlled extraction system) and safety systems (Atex direction and explosion protection system, safety and inspection system, fire protection system) which make it a product suitable for the different market needs. Years of experience have ensured that IMAS AEROMECCANICA was equipped with a range of silos that differ in size and storage capacity. We include the Silos with 14-18-24 Panels, the Silos on Legs, the Polygonal Silos. Filtering Silos 14 panels Filtering silos made specifically for the storage of waste deriving from wood processing, such as wood chips or sawdust, complete with side discharge extractor by means of a 280 mm diameter screw driven by a gear motor. Built under ISO 9001 quality control in the plant of IMAS, they are made in a polygonal shape with 14 sides corresponding to an average diameter of about 4000 mm, complete with ladder and parapet. The storage volumes vary from a minimum of 45 to a maximum of 120 m3; supplied in different configurations, the maximum height of the silo cannot exceed 16 metres. Equipped with a large surface area filter head, they combine storage characteristics with the possibility of filtration with operation in depression up to 6000 Pa. The sleeve cleaning system, with snap-ring connection, is carried out by shaking, through a vibrator motion attached to the sleeve holder frame,
