CNC lathe MS22-8

horizontal3-axismulti-spindle

Highly-dynamic slides with sliding guide (X-axis) Non-wearing Z-axis due to quills with hydrostatic support Chuck part machining with loading and unloading by robots Up to 16 tool holders with 1 or 2 axes and optional Y-axis can be used variably Versatility is the strong point of the MS22-8. Whether complex parts or different processes are involved – anything is possible More options for rear end machining with hydraulically locked and extremely fast swiveling synchronous spindle Already included: the operating system iXpanel i4.0 ready with 18.5” touch screen and Siemens S840D sl The expansion options Double four-spindle machine – a profitable upgrade option Additional part production time reduction due to simultaneous manufacturing of 2 workpieces 14 tool carriers with 1 or 2 axes (optionally also Y-axis) 2 swiveling synchronous spindles 2 rear slides (option) with 3 tools each, of which up to 2 are livefour Your advantage: Two identical or two different workpieces can be machined in parallel. Result: fast cycle times. Eight-spindle machining with simultaneous rear end machining Front end machining with up to 15 X/Z tool carriers (optional Y-axis) Cutoff end machining at the same time 1 swiveling synchronous spindle 1 rear slide Versatile machining options Machining of highly complex workpieces possible Your advantage: Reduced cycle time with time-determining rear end machining Pioneering multi-spindle technology Explore the virtually limitless machining flexibility and the advantages of the INDEX MS22-8 multi-spindle turning automatic. The adjacent animation shows you a wide variety of machining options on a multi-spindle machine.
