Robot charging station

DCoutdoor

Product overview
Contact charging station designed for Moliris autonomous robots (AGVs, AMRs and ASRs). The Moliris contact charging station delivers fast, high-current contact charging to minimise robot downtime and increase operational throughput. Compatible with batteries and systems requiring 12–58 V.

Benefits

• Maximum energy transfer — contact charging delivers higher current than inductive systems, reducing charge time and improving fleet availability.
• Reliable electrical contact — direct conductor contact ensures efficient, stable power transfer and consistent performance over time.
• Durable connectors — advanced materials rated for >30,000 docking cycles (roughly 4 charges per day for over 20 years), keeping maintenance costs low.

Safety & monitoring

• Connectors activate only when the robot is docked to protect operators; contacts are enclosed to prevent accidental damage and contamination.
• Protection rating IP54 for dust and splash resistance.
• Integrated display shows real-time charging progress, temperature, humidity and battery status. Web app enables remote monitoring, logging and data analysis.

Design and installation

• Compact footprint suitable for space-constrained industrial environments.
• Dedicated outdoor model with reinforced protective housing for reliable operation in harsh conditions.
• Wide compatibility with mobile robots operating at 12–58 V; supplied connector can be installed on the vehicle. Coupling may be manual or automated via third-party systems if Moliris KIT is not used.

Advanced features with Moliris Autonomous Navigation KIT

• Automatic docking when robots are equipped with the Moliris KIT or when controlled via available APIs.
• Flexible operation modes — acts as a single-robot Home or a multi-robot Charging hub with automatic booking and queuing.
• Store & forward capability — stores images, video and sensor data for transfer during charging when radio links are limited.

Technical specifications

• Product designation: Moliris Contact Charging Station
• Compatibility voltage range: 12 V – 58 V
• Connector durability: > 30,000 docking cycles (~4 charges/day for >20 years)
• Protection rating: IP54
• Charging type: Contact charging (direct conductor contact)
• Integrated display: real-time charging, temperature, humidity, battery status
• Remote monitoring: web app with logging and data analysis
• Automatic docking: supported with Moliris Autonomous Navigation KIT; APIs available
• Form factor: compact footprint; outdoor model available
• Modes: single-robot Home or multi-robot Charging hub with booking system
