Belt dosing unit MDS-2

pneumatic

The equipment is designed for dosing bread sticks in high-performance production environments. The operating principle of the machine is based on arithmetic counting of the number of items per package. Using a guided conveyor belt, the bread sticks are transported into four collection bins. Optical sensors in each bin count the preset number of sticks. Once the target quantity is reached, the product is automatically transferred into a box previously placed by the operator on the conveyor belt. Features Requires a pneumatic compressor with an inlet capacity of at least 100 l/min. Advantages of MDS-2: Pneumatic components by Camozzi (Italy) Frequency inverters by Hpmont (China) Control system based on Delta PLC (Taiwan) and Kinco touch panel (China) Control elements by EMAS (Turkey) Gear motors by Tramec and Transtecno (Italy) All product-contacting parts are made of materials approved for use with food products and environments Number of conveyors - 9 Conveyor speed, m/min - 0.3–4 Conveyor width, mm - 80, 200 Voltage - 400 V, 50 Hz Compressed air consumption, l/min - 50 Operating air pressure, bar - 3–6 Overall dimensions (L×W×H), mm - 4000 × 2000 × 2000
