Sliding gate RC3 137

sliding gate
sliding gate
sliding gate
sliding gate
Add to favorites
Compare this product


sliding, sectional
Operating mode
Product applications
steel, zinc


Burglary protection includes measures for prevention of unauthorised access to locked premises. Jansen is able to manufacture gate systems for the protection of building parts in different resistance classes with or without fire protection requirements. Jansen`s sliding gate SafeLine RC3 is tested successfully according to DIN T/S 18194:2020-07, RC3. Referred to RC3 standard, an accustomed acting offender attemps to break open the locked component with simple tools and a crowbar in a resistance time of 5 minutes. The door leaf consists of several 300-1000 mm wide elements (depending on the door width). The separate elements are reinforced by an inner frame and are joined to a sturdy door leaf through a special linking system. The thickness of the door leaf is 63 mm. The surface consists of zinc-coated steel sheets. The steel sheets and the fire protection filling are caulked all over. The running-in profile and the labyrinth profile are zinc-coated. Each door element is guided in ball bearing mounted castors. The cold-milled, zinc-coated C-profiles are mounted to the ceiling by means of brackets. Addtional brackets and joint clearance l


No catalogs are available for this product.
