Mini-excavator 25Z-1

crawlerdieselzero tail swing

Overview
The JCB 25Z-1 is a 2.5 tonne mini excavator with zero tailswing and Stage V emissions compliance, designed for easy manoeuvrability in confined sites and safe towing in regions with a 3,500 kg limit.

Performance

• Stage V Kohler engine 18.4 kW: approximately 5% lower fuel consumption versus previous unit.
• Load-sensing hydraulics with high- and low-flow options for a wide range of attachments.
• Auto kickdown track motors adapt to terrain changes to improve productivity and operator comfort.
• Optional bolt-on counterweight to enhance stability and lift performance.

Safety

• Follow-Me-Home worklights and the JCB 2GO system for operational protection and on-site visibility.
• Immobilizer (key or keypad) to prevent unauthorised use.
• Designated lashing points and compact footprint for secure transport and towing.

Service & ownership

• Steel bonnet with wide opening and external fuel fill for fast daily checks and refuelling.
• Colour-coded, internally routed hydraulic hoses on the arm to reduce damage and simplify maintenance.
• Bronze impregnated bushings with 500-hour greasing intervals and flat glass to lower repair costs and downtime.

Durability & construction

• Robot-welded boom and dipper in high-strength steel with internal reinforcement plates.
• Pressed-steel body panels for robust, repairable protection and optional cylinder guards.

Applications

• Urban and confined worksites requiring high manoeuvrability and easy transport.
• Rental fleets seeking machines with low operating costs, straightforward servicing and high availability.

Technical specifications

• Model: 25Z-1
• Brand: JCB
• Maximum digging depth: 2.82 m
• Dumping height: 3.16 m
• Engine power: 18.4 kW (Kohler Stage V)
• Operating weight: 2,550 kg
• Towable compliance: suitable for regions with a 3,500 kg towing limit
