Compact receiver HSV900

ruggedIP65

The HSV900 receiver is a mid-sized unit from the HSV MOSFET Series, designed to offer compact dimensions and minimize the aesthetic impact on the on-board system. It features a mounting hole for M10 stud bolts at the center of the back part and can be installed using four corner brackets or by fastening to the center nut. Terminal screws allow for easy connection to any system. - Power supply: 24/48 Vdc - 18 Mosfet outputs: 5A max each - Ideal for strong vibrations: No internal mechanical components, making it suitable for environments with constant and strong vibrations - Receiver feedback LED: Green and red LEDs indicate the state of transmission between transmitter and receiver via pulse code Small Dimensions The HSV900 receiver is designed to have small dimensions, minimizing its visual impact. The distance between mounting brackets is: - Width: 156 mm - Height: 165 mm Receiver Antenna The receiving antenna can be easily screwed onto the SMA type connector, allowing for flexible placement. Optionally, an external antenna with a 2 or 5 meter cable can be mounted, enabling installation in optimal reception locations, even inside electrical panels or metal structures. MOSFET Outputs Thanks to the MOSFET outputs, the receiver has no internal mechanical components, making it ideal for installations where strong and constant vibrations are present. - Frequency: 433.0525 > 434.7775 MHz - Modulation: 4GFSK - Sensitivity: -112dBm at 1.2Kbps - Control System: PLL - Antenna Impedance: 50 Ohm - Command Response Time: 50 > 100 ms - Power Supply: 24/48 Vdc - Antenna: External - Standby Current Consumption: 16mA at 220Vac - Operating and Storage Temperature: (-20°C)~(+55°C) / (-40°C)~(+65°C) (-4°F)~(+131°F) / (-40°F)~(+149°F) - Connecting Interfaces: Multi-core cable - Outputs: 18 configurable 5A MOSFETs - Degree Protection: IP65 - Dimensions: H184 x L190 x P64 mm - Weight: 780g - Housing: Nylon and glass fiber IP65 (PA6 30% GF)
