Angled torque wrench TQS series

cordless3/4"high-precision

Overview
Cordless battery-operated torque gun in straight design from the JUWEL TQS-Series. Available across a wide torque range (from small torques up to 15,000 Nm depending on model). Drive unit and 4-speed planetary gearbox developed and produced in Germany. Key elements include mechanical step adjustment, brushless PowerDrive motor, lithium-ion battery technology and fast charging.

Main features

• Cordless torque wrench available for torques between 100–15,000 Nm (model-dependent) with simple mechanical torque adjustment.
• 4 gears with 15 torque settings each (option to switch between up to 60 torque levels).
• Mechanical step adjustment: resistant to dirt and sunlight; operable with gloves.
• Brushless PowerDrive motor for efficient, maintenance-friendly operation.
• Lithium‑ion batteries with SafetyCell Technology; standard delivery includes two rechargeable batteries. Quick charger restores full capacity in under 30 minutes. Typical battery capacity: 6 Ah for continuous screwdriving.
• Electronically controlled precise torque: tool switches off automatically after successful fastening.
• Visual and acoustic battery charge indicator when defined levels are reached.
• Motor and electronics protected against dust.
• Drive and gearbox 100% developed and produced in-house (Rhineland-Palatinate, Germany); gearbox milled, geared and assembled internally.
• High-strength special alloys and selected bearings for high gearbox quality and long service life.
• High speeds for precise and fast bolting.
• Large accessory range (reaction arms, supports, adapters, brackets) manufactured via in-house CNC for quick availability.
• Compatible with JUWEL ReactionFree system to avoid external reaction/support in some applications.

Models & product highlights

• TQS series includes models from weight‑optimised small-torque units (e.g. TQS-065, TQS-095) up to robust high-torque units (e.g. TQS-130, TQS-220, TQS-300) and extended-range models (TQS-1000, TQS-1500).
• TQS-065: lightweight for small torques (max. 650 Nm).
• TQS-095: up to 950 Nm.
• TQS-130 / TQS-220 / TQS-300: robust designs for demanding bolting (TQS-300 up to 3,000 Nm).
• TQS-400–TQS-700: standard configuration often includes additional handle and modular geared bearings for safe handling at higher torques (screw connections up to 10,000 Nm depending on model).
• TQS-700 example: powerful model (max. 7,000 Nm).
• New high-capacity models: TQS-1000 (approx. 500–10,000 Nm) and TQS-1500 (up to approx. 1,050–15,000 Nm).

Notes

• All JUWEL torque guns are assembled and calibrated after order; calibration and testing follow international standards and company quality procedures.
• Accessories such as sliding supports and custom reaction arms can be manufactured to exact customer specifications.

Technical data (table)
Type | Square drive A | Item number | Torque (Nm) | Speed 1st gear (U/min) | Speed 2nd gear (U/min) | Speed 3rd gear (U/min) | Speed 4th gear (U/min) | Weight reaction arm (kg) | Weight (kg) | Height (mm) | Length (mm) | Width B (mm)
TQS-065 | 3/4" | 62 000 065 | 100 - 650 | 8 | 16 | 36 | 70 | 0.5 | 4.75 | 264 | 380 | 55
TQS-095 | 3/4" / 1" | 62 000 095 | 100 - 950 | 7.5 | 15.5 | 35 | 36 | 0.7 | 6.8 | 283-288 | 390 / 395 | 55/75
TQS-130 | 1" | 62 000 130 | 100 - 1,300 | 4.25 | 8.5 | 20 | 39 | 1.7 | 7.2 | 275 | 380 | 75
TQS-220 | 1" | 62 000 220 | 100 - 2,200 | 2.1 | 4.2 | 9.7 | 18.5 | 1.7 | 8.2 | 307 | 420 | 75
TQS-300 | 1" | 62 000 300 | 100 - 3,000 | 2 | 4 | 8.5 | 18.5 | 1.7 | 8.3 | 307 | 420 | 75
TQS-400 | 1 1/2" | 62 000 400 | 150 - 4,000 | 1.25 | 2.5 | 5.5 | 11 | 3.5 | 10.5 | 320 | 435 | 95
TQS-500 | 1 1/2" | 62 000 500 | 250 - 5,000 | 1 | 2 | 8.5 | 18.5 | 3.5 | 12.5 | 365 | 475 | 95
TQS-600 | 1 1/2" | 62 000 600 | 350 - 6,000 | 1 | 2 | 3 | 11 | 5.5 | 16 | 355 | 455 | 115
TQS-700 | 1 1/2" | 62 000 700 | 450 - 7,000 | 0.75 | 1.5 | 3.5 | 7 | 5.5 | 16 | 355 | 455 | 115

Technical specifications

• Series: TQS-Series (battery).
• Drive types (square drive): 3/4", 1", 1 1/2" depending on model.
• Torque ranges by model: from 100 Nm (TQS-065) up to approx. 15,000 Nm (TQS-1500); common ranges listed in table.
• Gearbox: 4-speed planetary gearbox with mechanical 15-step adjustment per gear (up to 60 torque levels).
• Motor: brushless PowerDrive motor.
• Battery: lithium-ion with SafetyCell Technology; 6 Ah typical; quick charge < 30 minutes; two batteries supplied as standard.
• Protection: dust-protected motor and electronics; durable gearbox materials and selected bearings.
• Weights and dimensions: vary by model (see table).
• Accessories: wide range including reaction arms, sliding supports, adapters, brackets and custom parts produced in-house (CNC).
