Tricot warp knitting machine TM 3

high-speed3 guide bars

THE HIGHLY EFFICIENT TRICOT MACHINE FOR THE BASIC NEEDS, ELASTIC AND RIGID ARTICLES Benefits Excellent price-performance ratio Needle bar with state-of-the-art carbon-fibre technology With an option of specially designed yarn deflection tube, change between filament yarn and elastane without dismantling any parts echnical Details Working width: 210" (+8" working width extension) 280" (+10" working width extension) Gauge: E 28, E 32 Bars / knitting elements: Individual needle bar (synchronously milled), tongue bar (synchronously milled), sinker bar with knock-over adjustment (chromium-plated sinkers), three ground guide bars (GB 1 up to GB 3 stitch-forming, shog up to 23 mm) All the bars are made of carbon-fibre-reinforced plastic. Warp beam support: 3 × 32" (free-standing) Option: 1 × 40" / 2 × 35" Batching device: Option: No. 34B, 52 Applications Swimwear Activewear Outerwear
