Excavator hydraulic milling cutter KRC 60
rotary

Excavator hydraulic milling cutter - KRC 60 - KEMROC Spezialmaschinen GmbH - rotary
Excavator hydraulic milling cutter - KRC 60 - KEMROC Spezialmaschinen GmbH - rotary
Excavator hydraulic milling cutter - KRC 60 - KEMROC Spezialmaschinen GmbH - rotary - image - 2
Excavator hydraulic milling cutter - KRC 60 - KEMROC Spezialmaschinen GmbH - rotary - image - 3
Add to favorites
Compare this product

Characteristics

Applications
for excavators
Specifications
rotary

Description

General
  • Product type: Bullhead cutter for excavators
  • Series: KRC Bullhead Cutters
  • Model: KRC 60
  • Primary use: rock and soft-rock cutting, trenching and surface milling


Applications
  • Recommended carrier: excavators 12–17 t (25,000–35,000 lb)
  • Typical sectors: construction, quarrying, tunneling and civil engineering


Technical data
  • Recommended excavator weight: 12 – 17 t (25,000 – 35,000 lb)
  • Rated power: 60 kW (80 hp)
  • Cutter length (A): 1200 mm (47 in)
  • Cutting width (B): 600 mm (24 in)
  • Average drum diameter (C): 545 mm (21 in)
  • Recommended rpm: 85 rpm
  • Recommended oil flow: 115 l/min (30 gal/min)
  • Max. oil flow: 155 l/min (41 gal/min)
  • Max. operating pressure: 400 bar (5800 psi)
  • Torque at 380 bar: 9100 Nm (6700 lbf·ft)
  • Cutting force at 380 bar: 33.0 kN (7500 lbf)
  • Max. rock compressive strength: 50 MPa
  • Weight: 850 kg (1765 lb)
  • Pick box: PH 22 HD Type
  • Number of picks: 56 pcs
  • Standard pick: 15/46/38/22 C
  • Standard hole pattern: LB20
  • Compatible rotation unit (KRM): KRM40


Configuration & maintenance
  • Standard pick type and LB20 hole pattern for quick replacement
  • Service access designed for field maintenance and pick replacement
  • Recommended hydraulic settings: 115 l/min and 380 bar (see technical data)


Notes
  • Technical drawing available on the product page
  • Values provided in metric units with US equivalents where indicated
