Ionizing air nozzle DD 106 (A) cleaningblow-offionizing
Add to favorites
Compare this product
Characteristics
- Fluid
- ionizing air
- Function
- cleaning, blow-off, ionizing
- Stream
- multi-channel
- Material
- plastic
- Applications
- industrial, for pharmaceutical applications, for the paper industry, for injection molding machines, cleaning machine, for machine tools, for hygienic applications, for surface treatment, for special applications, for electrostatic discharge
- Other characteristics
- compact, anti-static
- Orifice diameter
Min.: 0.25 in
Max.: 0.375 in
- Flow
Min.: 2.3 m³/h
(81.22 ft³/h)Max.: 5.7 m³/h
(201.29 ft³/h)- Pressure
0.2 bar, 1 bar
(2.9 psi, 14.5 psi)- Media temperature
Min.: 5 °C
(41 °F)Max.: 80 °C
(176 °F)
Description
The DD 106 discharge nozzles in the neXt® product family are designed to fit existing ball heads of 1/4" Ariana articulated hoses. This means that you may, for instance, extend your existing articulated hose system by adding deionising functionality. A greater electrostatic discharge reach and cleaning effect on the material to be discharged may be achieved with the additional support of compressed air.
Download Data Sheet DD 106
Specifications
Simple exchange of the existing nozzle
DD 106 Fits 1/4” Ariana articulated hose ball heads
DD 106 without articulated hose
DD 106 A with articulated hose
Touch-safe
