SATA III SSD YSSCSS5 series

internal

Yansen’s YSSCSS5 CFast, is a high-performance storage solution designed specifically for industrial applications. With its small form factor and SATA 3.1 interface, this device can be used as a boot device or data storage. Featuring TLC NAND Flash memory, the YSSCSS5 CFast delivers exceptional read and write speeds of up to 570/530 MB/s, making it ideal for high-intensity applications. The YSSCSS5 CFast is a reliable and durable storage solution that provides long-lasting performance for your industrial needs. Choose Yansen’s YSSCSS5 CFast for all your storage needs ranging from 256GB to 1TB. Specification Dimensions - CFAST L42.8mm * W36.4mm * H3.3mm Error±0.15mm 4K Random read(IOPS) - 61830(1TB) 4K Random write(IOPS) - 61750(1TB) Input voltage - DC 3.3V±5% Power consumption Idle - 0.28W(1TB) Power consumption Active - 1.85W(1TB) Data retention - 10years below 25 degree MTBF - 2 million hours ECC - Hardware BCH ECC capable of correcting errors up to 66- bit/1KB Features - Power management/TRIM/S.M.A.R.T./NCQ/Wear-leveling Operating Temp. - -20℃~75℃, -40℃~85℃ Storage Temp. - -55℃~105℃ Humidity - 5-95%
