Precision engineering workpiece clamping chuck JN06T

for turning applicationshigh-speedmanual tightening

Key features

• Steel body construction for increased rigidity and durability, enabling high-speed operation
• Max. static gripping force: 31 kN
• Max speed: 4000 rpm
• Net weight (with soft top jaws): 9.0 kg
• Moment of inertia: 0.033 kg·m²
• Gripping range (outer): 3–160 mm
• Gripping range (inner): 55–150 mm
• Matching soft jaws: SBS06
• Matching hard jaws: HBS06C
• Handle torque: 88.3 N·m

Product description
Versatile 165 mm manual scroll chuck by Kitagawa offering both inside and outside diameter gripping. The steel-body JN..T series is designed for precision turning and is supplied with interchangeable soft and hard top jaws for flexible clamping.

• Gripping range (outer): 3–160 mm
• Gripping range (inner): 55–150 mm
• Through hole: 45 mm
• Max speed: 4000 rpm

Further information
Top jaws are easily interchanged using cross tenon mounting. The chuck is supplied as a recess mount to adapt to a wide variety of spindle installations; optional mounting flanges are available for other spindle interfaces.

Technical specifications

• Model: JN06T
• Nominal diameter: 165 mm
• External gripping range: 3–160 mm
• Internal gripping range: 55–150 mm
• Through hole: 45 mm
• Handle torque: 88.3 N·m
• Max. static gripping force: 31 kN
• Max speed: 4000 min⁻¹ (rpm)
• Moment of inertia: 0.033 kg·m²
• Net weight (with soft top jaws): 9.0 kg
• Matching soft jaws: SBS06
• Matching hard jaws: HBS06C
