Multi-channel luminance and colour meter CA-510

digitalcompactUSB

Overview
The CA-510 is a compact display color analyzer designed for modern OLED, micro-LED and HDR displays. It extends luminance and chromaticity measurement ranges, improves low-luminance speed and provides enhanced waveform and flicker analysis for both R&D and production environments.

Compact Probe for High-Precision Measurement
The CA-510 uses a Ø10 mm measurement area with ±15° acceptance angle to capture light from wide-angle emitters. This configuration increases sensitivity in low-luminance regions, making it suitable for high-contrast OLED panels and dynamic driving systems.

Expanded Measurement Range
The CA-510 guarantees luminance measurements from 0.0002 to 20,000 cd/m² and chromaticity from 0.002 to 20,000 cd/m², enabling reliable readings from deep black levels to peak luminance values.

Fast and Repeatable Low-Luminance Measurement
Measurement speed is adapted to R&D and production: AUTO mode achieves 1 s readings at 0.0002 cd/m², reducing takt time and supporting efficient gamma tuning and inspection workflows.

Advanced Flicker and Waveform Analysis
Supports JEITA, VESA, FMA and VRR-Flicker (Konica Minolta method) with sampling up to 200 kHz. Provides detailed waveform output including color waveform (XYZ) for emission timing and RGB element evaluation.

Software Integration and Automation
Compatible with CA-S40 Ver.2.2 and CA-SDK2 for instrument control, data visualization and automation. Features include multi-channel calibration, residual light suppression and customizable AUTO modes.

Applications

• OLED and micro-LED display development
• Smartphone and automotive display evaluation
• Production line measurement and optimization
• Visual quality assurance and inspection

Features

• Expanded measurement range: Luminance 0.0002 to 20,000 cd/m²; Chromaticity 0.002 to 20,000 cd/m²
• Fast low-luminance measurement: 1 s at 0.0002 cd/m² in AUTO mode
• Waveform enhancements: Sampling frequency up to 200 kHz; waveform luminance range 0.2 to 20,000 cd/m²
• Software: Compatible with CA-S40 Ver.2.2 and CA-SDK2
• VRR-Flicker measurement in addition to JEITA, VESA and FMA methods

Technical specifications

• Model: CA-510
• Measurement area: Ø 10 mm
• Acceptance angle: ± 15°
• Accuracy guaranteed measurement distance: 30 ± 5 mm
• Luminance: Accuracy guaranteed range: 0.0002 to 20,000 cd/m²
• Accuracy (for white): > 0.0001 cd/m² — (no value); > 0.0002 cd/m²: ±9 %; > 0.0005 cd/m²: ±3.5 %; > 0.001 cd/m²: ±3 %; > 0.01 cd/m²: ±2 %; > 0.1 cd/m²: ±1.5 %
• Repeatability (2σ) AUTO: > 0.0001 cd/m² — (no value); > 0.0002 cd/m²: 10 %; > 0.0005 cd/m²: 3 %; > 0.001 cd/m²: 2 %; > 0.01 cd/m²: 0.35 %; > 0.1 cd/m²: 0.12 %; > 1 cd/m²: 0.10 %
• Chromaticity: Accuracy guaranteed range: 0.002 to 20,000 cd/m²
• Accuracy (for white): > 0.001 cd/m² — (no value); > 0.002 cd/m²: ±0.003; > 0.01 cd/m²: ±0.002
• Repeatability (2σ) AUTO chromaticity: > 0.001 cd/m² — (no value); > 0.002 cd/m²: 0.0030; > 0.01 cd/m²: 0.0012; > 0.1 cd/m²: 0.0005; > 1 cd/m²: 0.0003; > 10 cd/m²: 0.0002
• Flicker (Contrast): Measurement luminance range: 1 to 20,000 cd/m²; target frequency: 0.25 to 65 Hz
• Flicker accuracy examples: 30 Hz AC/DC 10% sine: ±0.3 %; 60 Hz AC/DC 10% sine: ±0.3 %
• Flicker repeatability (2σ): 20 to 65 Hz AC/DC 10% sine: 0.3 %
• XYZ (Flicker/XYZ modes): Luminance range: 1 to 20,000 cd/m²; target frequency: 0.25 to 200 Hz
• XYZ accuracy examples: 30 Hz AC/DC 10% sine: ±1.5 %; 60 Hz AC/DC 10% sine: ±2.2 %
• Flicker (JEITA): Luminance range: 1 to 20,000 cd/m²; frequency: 0.42 to 65 Hz; accuracy examples: 30 Hz AC/DC 4% sine: ±0.35 dB
• Waveform: Flicker mode luminance range: 0.2 to 20,000 cd/m²; sampling frequency: 200 kHz (changeable)
• Waveform XYZ: luminance range: 0.2 to 19,000 cd/m²; sampling frequency: 3 kHz (changeable)
• VRR-Flicker: Luminance range: 1 to 20,000 cd/m²; sampling frequency: 200 kHz (changeable); measurement target: 0.01 to 100 kHz; accuracy: 1 to 120 Hz AC/DC 10% sine: ±0.3 %
• Accuracy guaranteed measurement speed: AUTO Lvxy: 1 time/sec (> 0.0002 cd/m²), 5 times/sec (> 0.02 cd/m²), 20 times/sec (> 0.25 cd/m²)
• Flicker (Contrast) measurement speed: 20 times/sec
• Flicker (JEITA/VESA) measurement speed: 0.5 times/sec (at 1 Hz Pitch), 2.5 times/sec (at 10 Hz Pitch)
• VRR-Flicker sampling frequency for speed example: 3 kHz; observation example: 0.7 times/sec (at 1 s Obs.)
• Vertical synchronization frequency target: 0.5 to 240 Hz (luminance and chromaticity)
• Power supply: DC 5 V (USB bus power or RS communication connector)
• Operating conditions: 10 to 35°C, RH ≤85%, no condensation
• Storage conditions: 0 to 45°C, RH ≤85% (at 35°C), no condensation
• Notes: Measurements specified under Konica Minolta’s standard light source (6,500 K). Environmental conditions for accuracy: 23°C ±2°C, RH 40% ±10%; reading fluctuation examples: Luminance ±2% for white; Chromaticity at 100 cd/m²: ±0.002 for white, ±0.003 for monochrome.
