Analog timer 571T
electronicmulti-functionwith housing

analog timer
analog timer
Add to favorites
Compare this product


Characteristics

Technology
electronic, analog
Function
multi-function
Mounting
with housing
Product applications
for general purposes, LCD display
Other characteristics
programmable, adjustable, 8-digit
Voltage

Min.: 18 V

Max.: 230 V

Description

LCD touch multifunction preset counters Characteristics Fast count input, works with our Limes measuring system (250 kHz/HTL, 1 MHz/RS422). 4 switching outputs to work as limit values (reaction time < 1 ms). Scalable analog output (reaction time < 150 ms), resolution 16 bit, -10 ... +10 V, 0 ... 20 mA or 4 ... 20 mA. Serial interface RS232 or RS485 for reading data in and out. Sensor power supply 24 V DC / 150 mA (AC version) or U B - 1 V / max. 250 mA (DC version). 96 x 48 mm DIN housing, IP65. Touch display with 8-digit display value and menu-driven programming. 2 relay outputs that can be assigned to the limit values. Benefits AC and DC supply voltage in one unit. Measuring function can be programmed for RPM, speed, speed from elapsed time, machine cycle time, throughput time (reciprocal rotary speed), as well as numerous count and stop-watch functions. 4 switching outputs; can also be programmed as a tracking preset. Freely programmable. Large 13 mm high LCD display, 8-digit, with adjustable brightness. Tri-color – red / green / yellow – programmable. Display linearization with teach function.
