USB interface module PCD-430A series

onnect the sensor interface to a PC via USB port. The PC will be a measuring instrument. Up to 4 units can be stacked for measurement in 16 channels. Features ●Input of strain and voltage can be selected for each channel ●Easy sensor connection using various types of input adapter (An input adapter is required for measurement.) ●Connects to PC using USB interface ●Measurement using 1 unit with 4 channels, up to a maximum of 4 units with 16 channels possible (Allowed combination of the PCD-400A) ●4 units simultaneous sampling using the connection connector set ST-1A (optional accessory) ●Dynamic data acquisition software (DCS-100A) standard accessory supporting 　Windows Vista, and Windows 7,Windows 8/8.1(Japanese/English, 32/64 bit) ●TEDS compatible (UI-10A, UI-11A) ●Input adapter 　Input adapter for strain gage transducer UI-10A (TEDS compatible) 　Input adapter for strain gage UI-11A (TEDS compatible) 　Input adapter for strain gage with operating lever UI-15A 　One-touch lock type input adapter for strain gage UI-16A 　One-touch type input adapter UI-55A 　Voltage input adapter UI-30A ●Compact, lightweight ●Analysis of data using the analysis software (optional accessory) (DAS-200A) is possible.
