Swivel caster TAU + P60base platewith ball bearingwith brake
Add to favorites
Compare this product
Characteristics
- Type
- swivel
- Mount
- base plate
- Other characteristics
- with ball bearing, with brake, heavy-duty, pressed steel, polyurethane, aluminum
- Load capacity
Max.: 800 kg
(1,764 lb)Min.: 250 kg
(551 lb)- Wheel diameter
Max.: 250 mm
(9.843 in)Min.: 80 mm
(3.15 in)- Tread width
Max.: 60 mm
(2.36 in)Min.: 40 mm
(1.57 in)
Description
ALUMINIUM CORE - CAST POLYURETHANE COATING.
Cast polyurethane coating, hardness 95±3 Shore A.
Core in die-cast aluminium alloy.
High load capacity; excellent smooth and noiseless running; high resistance to wear and tear, oils and greases.
Temperature range: -30°C / +80°C (-22°F / +176°F).
Hub with: shielded precision ball bearings; standard roller bearing.
HEAVY DUTY CASTORS
Finish: electro-zinc plated, white.
Top plate in pressed steel-sheet.
King-pin riveted to the top-plate.
Thermoplastic dust protection ring (water-resistant).
Hardened steel ball races.
Swivel fork in pressed steel sheet.
Hardened steel balls.
Thermoplastic dust seal (waterproof).
Balls retaining ring in pressed steel-sheet.
Self-locking nut.
