Custom circuit board BD-SL-i.MX6 SBC

The BD-SL-i.MX6 kit (formerly the SABRE Lite board) is a low-cost development platform featuring the powerful i.MX6 Quad applications processor. It includes an accessory kit option with a 5V Power Supply, 16GB microSD card with Linux OS, and Serial Console Cable. Although the BD-SL-i.MX6 can be used in mass production, we recommend customers consider our Nitrogen6 family of boards. Specifications Chipset (MPU) x4 Cortex-A9 @ 1 GHz (via NXP’s i.MX 6 processor) Dimensions (L x W) 82 x 82 Audio Input/Output Camera 2x Parallel, 1x MIPI Display HSMI, LVDS, RGB Form Factor Single Board Computer Interfaces - General PCIe Gen 2.0 via J23 Daughter Board 4x USB2 1x GbE 3x I2C 1x SPI (via J15) 2x RS-232 (more available via J15) Memory 1GB DDR3L Operating Temperature 0° - +70°C Become an Ezurio Customer to Gain Exclusive Access to Our Design Experts Antenna Scans Antenna selection and placement Custom antenna design Worldwide EMC testing / certifications Embedded RF hardware / firmware design Cloud architecture and integration Mobile application development Product & Industrial Design
