FEATURES
DIMENSIONS AND PERFORMANCE
Wheelbase: 3.68 m (145 in.)
Approximate overall length: 9.85 m (388 in.)
Gross vehicle weight: 22,680 kg (50,000 lbs)
Total weight: 16,330 kg (36,000 lbs)
Cab: single driver seat with left side passenger / assistant seat
Cab set on rubber mounts, soundproof to at least 73 dBA
Power Steering
Windows: Tinted safety glass
Pneumatic driver’s seat
AXLES
Pneumatically actuated full lock planetary axles with electrical control
Front: capacity 11,340 kg (25,000 lbs) directional drive axle with double cardan joint
Rear: capacity 11,340 kg (25,000 lbs)
BRAKES
Fully pneumatic
Type S cam
Comply with FMVSS 121
ENGINE
Power: 186-242 kW (250-325 HP)
TRANSMISSION
Electronic automatic
4 to 6 forward gears, 1 reverse
TRANSFER CASE
1 to 2 speed air shift
4x4, front declutch or proportioning differential (driver-controlled)
FUEL SUPPLY
Tank capacity: 606 liters (160 US gallons)
ELECTRICAL SYSTEM
12 V electrical system
Multifunctional joystick for hydraulic controls
TIRES
High traction radial (tubeless)
Size: 425/65 R22.5
ACCESSORIES
Heater: 16.12 kW (55,000 BTU/h)
Sunshade
Amber strobe light
Work lights
Heated mirrors
Intermittent windshield wipers
Multifunctional joystick control box
Adjustable tilt / telescopic steering column
