Corded electric screwdriver EHS series

straightwith torque controlfor automatic machines

Overview
The EHS handheld in-line screwdriver features a straight-head design for broad process compatibility and compact integration with Leetx automatic screw feeding systems, enabling reduced weight and size while maintaining precise tightening control.

Highlights

• Torque control
• Angle control
• Multi-stage tightening strategy
• Process control integration

Key performance indicators

• Maximum torque: 15 N·m
• Maximum rotational speed: 2450 rpm
• Net weight: 0.73 kg

Features & advantages

• Highly flexible cable design for straightforward on-site wiring
• High-precision nutrunner with system torque accuracy ±5% at 6σ
• Torque control combined with angle monitoring via independent torque sensor and angle encoder
• Standard straight-head form factor compatible with a wide range of processes
• Optimized for compact integration with automatic screw feeding systems (Leetx)

Structure & drawings
Dimensional references and system architecture drawings are provided to support installation and integration.

Related applications

• Motor vehicle assembly
• Auto parts manufacturing
• Motor control modules
• Power battery assembly
• Consumer electronics
• White goods production
• Laboratory testing

Product variants

• EHS-Screwdriver
• EHA-Screwdriver
• EHS-Nutrunner
• EHA-Nutrunner
• EFS-Fixtured-Spindle

Technical specifications

• Series / model family: EHS
• Maximum torque: 15 N·m
• Maximum rotational speed: 2450 rpm
• Net weight: 0.73 kg
• System torque accuracy: ±5% at 6σ
• Independent torque sensor
• Angle encoder for angle monitoring
• Standard straight-head design
• Multi-stage tightening strategy supported
• Process control capability (integration with tightening control systems)
• Compatible with Leetx automatic screw feeding systems
• Highly flexible cable for on-site wiring
