Electric concrete internal vibrator Pendulum

Description
Our pendulum concrete vibrators combine pendulum supports at both ends with high-quality components to provide long service life and low maintenance. They improve concrete wall finish and overall operator productivity. Units are available with several needle diameters, lengths and hose options.

Available vibrating needles (table)

• Ø 35 mm — Amplitude 1.2 mm; Compaction 6 m³/h; Needle length 420 mm; Action Ø 50 cm²; Centrifugal force 125 kg; Hose 4/5/6 m; Vibration speed 12,000 rpm
• Ø 40 mm — Amplitude 1.5 mm; Compaction 7 m³/h; Needle length 520 mm; Action Ø 55 cm²; Centrifugal force 160 kg; Hose 4/5/6 m; Vibration speed 12,000 rpm
• Ø 45 mm — Amplitude 1.9 mm; Compaction 9 m³/h; Needle length 520 mm; Action Ø 60 cm²; Centrifugal force 230 kg; Hose 4/5/6 m; Vibration speed 12,000 rpm
• Ø 50 mm — Amplitude 2.2 mm; Compaction 12 m³/h; Needle length 520 mm; Action Ø 70 cm²; Centrifugal force 275 kg; Hose 4/5/6 m; Vibration speed 12,000 rpm
• Ø 60 mm — Amplitude 2.5 mm; Compaction 15 m³/h; Needle length 600 mm; Action Ø 80 cm²; Centrifugal force 310 kg; Hose 4/5/6 m; Vibration speed 12,000 rpm

Available engines

• Gasoline: Rato — R210, 6.5 HP
• Gasoline: Honda — GX160, 5 HP
• Gasoline: Kohler — CH270, 6.5 HP
• Diesel: Lombardini — 15LD225, 5 HP
• Electric: 2 Kva, 220 V

Available configurations / Details pictures

• Fixed base model
• Turning base model
• Vibrator-equipped standard configuration (illustrated)

Notes
Data and sizes are for reference only; the company reserves the right to make changes without notice.

Technical specifications

• Product: Pendulum Vibrator
• Pendulum supports on both ends for enhanced durability
• Low maintenance thanks to high-quality components
• Improves concrete wall quality and operator efficiency
• Needle diameters: Ø 35 / 40 / 45 / 50 / 60 mm
• Amplitude per diameter: 1.2 / 1.5 / 1.9 / 2.2 / 2.5 mm
• Compaction power: 6 / 7 / 9 / 12 / 15 m³/h
• Needle lengths: 420 / 520 / 520 / 520 / 600 mm
• Action area: 50–80 cm² depending on diameter
• Centrifugal force: 125–310 kg depending on diameter
• Hose lengths available: 4 m / 5 m / 6 m
• Vibration speed: 12,000 rpm
• Engine options: gasoline, diesel, electric (see list above)
• Configurations: fixed base, turning base, vibrator-equipped unit
