Magnetic field tester UI9730

for electrical equipmentfor electronic parts

• Parameters to be measured (absolute value): Measure hypo-class U, Iout, Hz, Hc, Br, Bm, Hm, Br /Bm, μm, magnetic core loss, B-H curve, U curve and I curve • Output capacity of the high frequency power: Uout: 1~300V, Iout: 0.05~5A, Pout: 300VA, frequency: 10~300kHz • Accuracy: 2% • With 12-bit high-speed A/D, sampling rate up to 40MHz, ensuring data precise and stable test result • Supermaximal database, suitable for almost all kinds of magnetic material in market, such as: circle, E, U, ETD-EER, JAR, RM, EP, PM, EL, ER, PQ, EFD, plane E, etc • Perfect software interface enables observation of curve in detail • Meet international test requirements for magnetic particle ASTM E1444, ASTM E709-08,UL1993 S, UL6500.
