Box PC IBOX-MTL0

embeddedIntel® Core™ Ultra 7 155HIntel® Core™ Ultra 5 125H

Overview
The IBOX-MTL0 is a 3.5" embedded board based on Intel® Core™ Ultra series (Meteor Lake / Arrow Lake) SoCs. It offers multi-display output, a wide DC input range and extensive I/O for industrial AI edge computing and embedded applications.

Key Features

• On-board Intel® Core™ Ultra series (Meteor Lake-U/H and Arrow Lake-U/H)
• 1x 262-pin SO-DIMM socket, up to 48 GB DDR5-6400 MT/s
• Multi-display support: 2x HDMI, LVDS, 2x USB-C (DisplayPort)
• Supports 4K/2K resolution displays
• Two Intel® 2.5 Gigabit Ethernet ports
• Wide DC input: 12–24 V
• Storage and expansion: M.2 and SATA III support

I/O & Connectivity

• 2x HDMI
• 2x USB-C with DisplayPort
• LVDS interface
• SATA III
• 2x COM, 2x UART
• Up to 8x USB (USB3.1 and USB2.0)
• 2x RJ45 (Intel® 2.5 GbE)
• 1x DIO

Main Features / Highlights

• 3.5" form factor for compact industrial deployments
• Designed for AI edge computing with compatibility for Intel® AI solutions
• Support for high-resolution 4K displays and multi-display setups
• Wide-voltage DC input suitable for embedded, vehicle and industrial environments

Technical specifications

• Model: IBOX-MTL0
• CPU: Intel® Core™ Ultra series (Meteor Lake and Arrow Lake SoCs)
• Memory: 1x 262-pin SO-DIMM, up to 48 GB DDR5-6400 MT/s
• Graphics / Display: 2x HDMI, LVDS, 2x USB-C (DP), 4K/2K support
• Ethernet: 2x Intel® 2.5 Gigabit Ethernet ports
• Storage: SATA III, M.2 expansion supported
• USB: Up to 8x (USB3.1 and USB2.0)
• Serial / Control: 2x COM, 2x UART, 1x DIO
• Power Input: DC-IN 12–24 V
• Form Factor: 3.5" embedded single-board computer
