Belt shot blasting machine LSBH-76×35

for metalautomatic

The LSBH-76×35 has a versatile jigging basket that is 76 inches long and 35 inches in diameter allowing for a wide variety of product blasting possibilities. The replaceable manganese cabinet liners will make the machine endure a long blasting life and be easy to maintain for many years. The simple operation with adjustable cycle times will improve production time and won’t require extensive training. Dual hand controls and a door locking valve that prevents the door from closing in the event of air pressure loss will keep the operator safe. The LS TurboShot™ blast wheel is belt driven to protect the motor and make it easy to maintain. The blades on the LS TurboShot™ wheel are bi-directional allowing for reversing blasting for an all angle clean. Features All steel frame and cabinet construction with structural steel base Reversing impeller wheels for thorough cleaning Door safety interlock switch Basket bearings: heavy-duty four bolt flange, Superior bearing protection Forklift moving support built into blaster Sealed bearings with grease fittings Automatic timer with adjustable time settings Load basket from top or front Analog shot indicating ammeters Technical Specifications Basket Dimension 76”L x 35” diameter Work Space 70” x 30.25” diameter Overall Dimensions 101″ x 58″ x 145″ HP of Blast Wheels (STD)* 2ea x 10HP Basket HP (STD) 1HP (0.75 kw) Basket Weight Capacity (Approx) 1000lbs Dust Collector Std** DC-3 (5HP)
