Vertical baling press V85

front-loadingfor cardboardfor plastics

Specially designed for high outputs and maximum compaction, the V85 tyre baler can produce 4–6 PAS180 bales per hour, which means processing 400–500 standard car or light commercial tyres per hour. The V85 helps reduce storage requirements by up to 80% and transport up to 60%, while compacting bales for use in construction, landfill and even fuel projects in many countries worldwide. Recommended for tyre recyclers, waste management companies, car dismantlers and tyre depots. Also suitable for baling card, plastic and wool. FEATURES 300-litre oil tank cools the machine for continuous use Dual bale size selectable with a flick of the switch 20% greater bale weight than competitors, reducing labour, transport and consumables 15-kilowatt power pack for speed and long-stroke cylinders for optimal compaction Large filling chamber for easy loading, rear bale discharge Double row of high-tensile retention fingers Central greaser SPECIFICATIONS Bale size: 1400mm H (variable) x 1550mm W x 800mm D Tyres bales per hr: 4 to 6 bales 80 to 140 tyres per bale Cycle time: 55 seconds Dimensions: 4875mm H x 3315mm W (including power pack) x 1190mm D Rear bale discharge Power: 3 phase 380/440 volt. 15 kW motor Fill Opening: 1,960mm x 1,100mm Dual pressure select 25mm high carbon steel press plate & retention fingers Machine weight: 5500 kg Noise level: 76 dB EN16500 compliant IP54 Standards OPTIONS Diesel drive system Hook-lift transport frame Mobile version Special application conversions Annual service contract Remote maintenance 22 kW 3 phase 380/440 V power pack Oil cooler combined with oil heater Conveyor fill
