In-line pile turner

with centering systemfully-automatic

Overview
The ST-100 slab turner is engineered for efficient, precise handling and reorientation of flat substrates in industrial production lines and workshops. Its modular concept supports integration into conveyors and automation systems and enables safe, repeatable turning and positioning operations without manual handling.

Materials

• Ceramic and porcelain
• Marble
• Glass composites
• Wood

Operating modes

• 180° turning
• Bypass
• Off-center (eccentric) turning
• Centering and off-centering of slabs

Features

• Opposed knee supports driven by geared motor for controlled transport
• Geared motor with guided mounting on chassis for repeatable motion
• Fixation system to prevent impacts during turning
• Touchscreen HMI for easy operation and programming
• Electrical and mechanical protections compliant with CE standards

Technical specifications

• Operating modes: 180° turning; Bypass; Off-center turning; Centering and off-centering
• Drive: geared motor(s) with guided system on chassis
• Support: opposed knee supports driven by geared motor
• Fixation: anti-impact fixation system for safe turning
• Control: touchscreen interface for programming and operation
• Safety: electrical and mechanical protections according to CE requirements
• Suitable for: ceramic & porcelain, marble, glass composites, wood
