Network server IEM304-2D-2C

webembeddedindustrial

The embedded mounting IEM304-2D-2C module integrates serial device networking, CAN device networking, Modbus gateway, CAN relay and CAN to serial conversion and other functions. The IEM304-2D-2C supports one 10/100Base-T(X) port, 2 TTL serial ports and 2 TTL CAN ports. The server module can be managed via WEB and supports various network protocols, such as IP, ARP, UDP, TCP, ICMP, HTTP, Modbus TCP, Modbus RTU / ASCII, HTTPD, WebSocket, RealCOM, RFC2217, DHCP Client, DNS, etc. Its CAN port or serial port supports various network transmission modes, such as UDP, UDP Multicast, TCP Client / Server, Pair Connection Master / Slave, Modbus TCP / RTU / ASCII, Httpd Client, WebSocket Client, etc. It supports CAN and serial port interface conversion, and virtual com port function. The 4 port embedded server module supports hardware watchdog, and reset, factory reset, designed with indicators. It features low power consumption, wide temperature range, compact modular design. The surface mounted female header is easy to easy and maintain, flexible for PCBA and customize interface connection mode. Developed with industrial components, high performance low power processor, the module can work reliably in multiple harsh environments with -40℃ – + 85℃ wide temperature range. The products can be widely used in industrial automation, comprehensive energy, intelligent transportation, smart city, smart mining and other fields.
