Continuous flight auger (CFA) drilling rig HR 260 DW

diaphragm wallrotaryhydraulic

The HR 260 is a self erecting, 75 ton drilling rig particularly suitable for drilling great diameters using the kelly bar system and with casing tubes directly with the rotary. The HR 260 is able to perform the following applications - Drilling large diameters and great depths with augers or buckets - Execution of direct rotary drilling with casings and casing oscillator - Continuous Flight Auger (CFA) & Diaphragm Walls - Execution of Double Head drilling The HR 260 is available in the following two versions HR 260 CP – the standard version, is equipped with a Pull-down Cylinder which exerts it’s force on the rotary, and is principally utilized for drilling large diameter bore holes. The rotary is able to work with a stroke of 6.100 mm (20 ft) approx. The HR 260 CP uses a parallelogram system of articulation guaranteeing a notable range or motion 1.000 mm (3.3 ft). HR 260 THD – available upon request, The THD system moves the rotary by utilizing a crowd winch, allowing the rotary to be used along a larger stroke of the mast, 10 m (33 ft) approx. The THD version is particularly useful for driving and extracting casing tubes directly by the rotary, and without a doubt increasing your daily productivity.
