- Machine-tools
- Machining Center
- 3-axis machining center
- MAKINO Milling Machine
3-axis CNC machining center V77 GraphiteverticalHSK A-63HSK F63
Add to favorites
Compare this product
Characteristics
- Number of axes
- 3-axis
- Spindle orientation
- vertical
- Spindle mount
- HSK A-63, HSK F63
- Number of tool stations
- 40 tools, 30 tools, 80 tools
- Other characteristics
- high-speed
- X travel
1,200 mm
(47.24 in)- Y travel
700 mm
(27.56 in)- Z travel
640 mm
(25.2 in)- Rotational speed
20,000 rpm, 30,000 rpm
(125,664 rad.min-1, 188,496 rad.min-1)- Work feed X-axis
20,000 mm/min
(13.12 in/s)- Work feed Y-axis
20,000 mm/min
(13.12 in/s)- Work feed Z-axis
20,000 mm/min
(13.12 in/s)- Table load capacity
2,500 kg
(5,512 lb)- Tool weight (max)
8 kg
(17.6 lb)- Tool-changing time
5 s
Catalogs
No catalogs are available for this product.
